SimTech ProFlame 1 - Page 31

1. 6 Stage flame adjustment
2. Pilot adjustment
3. Inlet Pressure Tap
4. Outlet Pressure Tap
5. Pilot Outlet
6. Main Gas Outlet
7. Main Gas Inlet
1
2
3
4
6
5
7
1
2
3
4
6
5
7
S.I.T. 886 VALVE DESCRIPTION
Blue LCD display
ON/OFF display
THERMOSTAT Key
UP/DOWN Arrow Key
MODE Key
PROFLAME 2 HANDHELD AND DISPLAY
31
SUREFIRE ELECTRONIC IGNITION SYSTEM
S.I.T. PROFLAME 2 TROUBLESHOOTING
SimTech Proflame II
