JP1JP1
NCNC
NONO
MOMMOM
CONTCONT
SE2
SE1
STOP
DN
UP
SEQ
12
GND
POWERPOWER
SAFETY
STOP
JP1
+
JP3
JP4
J1
NC
NO
MOM
CONT
LOW VOLTAGE SWITCHING CONNECTIONS
STOPSTOP
DNDN
UPUP
SEQSEQ
1212
GNDGND
++
N.C.
N.O.
N.O.
3 BUTTON STATION
3 BUTTON STATION
NOTES:
1) SHOULD BE USED WITH REVERSING SENSORS
2) SHOWN CONFIGURED FOR A N.C. STOP BUTTON
2 BUTTON STATION
JP1JP1
NCNC
NONO
MOMMOM
CONTCONT
DNDN
UPUP
SEQSEQ
1212
GNDGND
++
N.O.
N.O.
2 BUTTON STATION
SEQSEQ
1212
GNDGND
++
N.O.
SEQSEQ
1212
GNDGND
++
1
2
3
RED
WHITE
BLACK
RECEIVER
SEQUENCING CONTROL SINGLE CHANNEL RADIO
NOTES:
1) CAN BE USED WITH ANY MOMENTARY, DRY
CONTACT SUCH AS KEY SWITCHES, CARD READERS,
RADIO CONTROLS, ETC..
2) TWO OR MORE SWITCHES CAN BE WIRED IN
PARALLEL.
3) CONTROL WILL FOLLOW A SEQUENCE WITH EACH
PULSE (UP, STOP, DOWN, STOP, UP, .....)
NOTES:
1) WIRING SHOWN IS STANDARD BUT MAY VARY WITH
MANUFACTURER. CHECK INSTRUCTIONS WITH RADIO
RECEIVER FOR DIFFERENCES BEFORE WIRING.
NOTES:
1) SHOWN REQUIRING CONSTANT PRESSURE ON THE
SWITCH FOR THE MOTOR TO OPERATE.
2) SWITCH MUST BE IN VIEW OF THE DOOR
INSTALLERS MANUAL
PAGE: 3 OF 5
