DC Inverter UNI SPLIT Series Duct Type Unit
13
2) When two or more outdoor units are to be installed side by side.
Unit: mm
A~E H
b
H
d
H
(mm)
a b c d e
A,B,C — ≥300 ≥300 ≥1000 — —
A,B,C,E — ≥300 ≥300 ≥1000 — ≥1000
D — — — — ≥2000 —
D,E — — — — ≥2000 ≥1000
B,D
H
b
<H
d
H
d
>H — ≥300 — ≥2000 —
H
b
>H
d
H
d
≤1/2H — ≥250 — ≥2000 —
1/2H<H
d
≤H — ≥300 — ≥2500 —
B,D,E
H
b
<H
d
H
b
≤1/2H — ≥300 — ≥2000 ≥1000
1/2H<H
b
≤H — ≥300 — ≥2500 ≥1000
H
b
>H Prohibited
H
b
>H
d
H
d
≤1/2H — ≥250 — ≥2500 ≥1000
1/2H<H
d
≤H — ≥300 — ≥2500 ≥1000
H
d
>H Prohibited
