2.2.6.3 Drain Riser with Pump Unit Considerations
(1) For the unit with the condensate pump, only one drain port at the side
close to the electric box is prepared and only through it the drain hose can
be connected.
I
tem
M
odel
Drain pipe
(
inside dimension
)(mm)
ASD-12BI2
Ф
26
ASD-18BI2
ASD-24BI2
ASD-36BI2
ASD-42BI2
ASD-48BI2
(2) For the unit with the condensate pump, two drain ports at the bottom are
defaulted to be factory plugged with drain caps. After the installation of
the drain hose, these two drain ports also need to be insulated properly
with the same way aforementioned.
(3) The lifted installation height of drainage pipe is less than 1,000mm, as is
shown in the following figure.
