DC Inverter UNI SPLIT Series
Duct
Type Unit
38
2.3.2 Electrical Parameters
2.3.2.1 Wire Specifications and Fuse Capacity
Model
Power supply
Fuse
capacity
Min. sectional
area of power
cord
V/Ph/Hz
A mm²
Indoor unit
220
-
240V ~50/60
Hz
3.15
1.0
Model
Power supply
Circuit
breaker
capacity
Min. sectional
area of power
cord
V/Ph/Hz
A mm
2
ASGE-12BI2
22
0
-
240V
~50/60Hz
1
6
1.5
ASGE-18BI2
16
1.5
ASGE-24BI2
20
2.5
ASGE-36BI2
32
4.0
ASGE-42BI2
32
4.0
ASGE-36BI2-3
380
-
415V
3
N~50/60Hz
16
1.5
ASGE-42BI2-3
16
1.5
ASGE-48BI2-3
16
1.5
NOTES:
①. Fuse is located on the main board.
②. Install a circuit breaker near the outdoor units with at least 3mm contact gap.
The units must be able to be plugged or unplugged.
③. Circuit breaker and power cord specifications listed in the above table are
determined based on the maximum power input of the units.
④. Supply cords of parts of appliances for outdoor use shall not be lighter than
polychloroprene sheathed flexible cord (code designation 60245 IEC 57).
⑤. Specifications of circuit breaker are based on a working condition where the
working temperature is 40°C. If working condition changes, please adjust the
specifications according to national standards.
