Installation and Maintenance

Service Manual

Above data is subject to change without notice.

No.

Description

Part Code

Qty

ASH-09AIE2 ASH-12AIE2

Product Code CB146W36201_L31222 CB146W36101_L31222

1 Electric Box Assy 10000100119 10000100121 1

2 Electric Box Sub-Assy 10000500050 10000500052 1

3 Main Board 30138000458 30138000459 1

4 Reactor 43130184 43130184 1

5 Terminal Board 42010313 42010313 1

6 Wire Clamp 71010003 71010003 2

7 Front Grill 22413043 22413043 1

8 Front Panel Assy 0153304802 0153304802 1

9 Axial Flow Fan 10333004 10333004 1

10 Chassis Sub-assy 0280330401P 02803304P 1

11 Fan Motor 1501308506 1501308506 1

12 Top Cover Sub-Assy 01253073 01253073 1

13 Motor Support 01703104 0170310401 1

14 Condenser Assy 01100200141 01100200142 1

15 Rear Grill 01473009 01473009 1

16 Electric Expand Valve Fitting 4300876701 4300876701 1

17 Electronic Expansion Valve 07135228 07135228 1

18 Valve 07100003 07100003 1

19 Big Handle 262334332 262334332 1

20 Cut off Valve Assy 07133474 07133474 1

21 Valve Support 0171314201P 0171314201P 1

22 Right Side Plate Sub-Assy 0130317801 0130317801 1

23 4-Way Valve Assy 03073151 03073145 1

24 Clapboard Sub-Assy 0123338502 0123338502 1

25 Magnet Coil 4300040050 4300040050 1

26 Compressor and Fittings 00103896G 00103896G 1

27 Electrical Heater 7661281401 7661281401 1

28 Drainage Connecter 06123401 06123401 1

29 Electrical Heater (Chassis) 7651000414 7651000414 1
