Sinclair ASH-12AIE2 Service Manual

3
Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Outdoor Unit Model ASH-09AIE2 ASH-12AIE2
Outdoor Unit Product Code CB146W36201_L31222 CB146W36101_L31222
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO.,LTD.
ZHUHAI LANDA
COMPRESSOR CO.,LTD.
Compressor Model QXA-A091zE190A QXA-A091zE190A
Compressor Oil RB68EP RB68EP
Compressor Type Rotary Rotary
Compressor Locked Rotor Amp (L.R.A) A 20 20
Compressor Rated Load Amp (RLA) A 4.5 4.5
Compressor Power Input W 942 942
Compressor Overload Protector 1NT11L-6233 1NT11L-6233
Throttling Method Electron expansion valve Electron expansion valve
Set Temperature Range °C 16~30 16~30
Cooling Operation Ambient Temperature
Range
°C -15~43 -15~43
Heating Operation Ambient Temperature
Range
°C -20~24 -20~24
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Ф7 Ф7
Condenser Rows-n Gap
mm
1-1.4 2-1.4
Condenser Coil Length (LXDXW) mm 710X19.05X508 710X38.1X506
Outdoor Unit Fan Motor Speed rpm 900 900
Outdoor Unit Fan Motor Power Output W 30 30
Outdoor Unit Fan Motor RLA A 0.36 0.36
Outdoor Unit Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume m
3
/h 1600 1600
Outdoor Unit Fan Type Axial-ow Axial-ow
Outdoor Unit Fan Diameter mm Ф400 Ф400
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure
for the Suction Side
MPa 2.5 2.5
Outdoor Unit Sound Pressure Level (H/M/L) dB (A) 51/-/- 53/-/-
Outdoor Unit Sound Power Level (H/M/L) dB (A) 62/-/- 63/-/-
Outdoor Unit Dimension (WXHXD) mm 776X540X320 776X540X320
Outdoor Unit Dimension of Carton Box
(LXWXH)
mm 848X360X580 848X360X580
Outdoor Unit Dimension of Package
(LXWXH)
mm 851X363X595 851X363X595
Outdoor Unit Net Weight kg 28 29
Outdoor Unit Gross Weight kg 31 32
Refrigerant R410A R410A
Refrigerant Charge kg 0.7 0.85
Connection
Pipe
Connection Pipe Length m 5
5
Connection Pipe Gas Additional Charge g/m 20
20
Outer Diameter of Liquid Pipe mm Ф6
Ф6
Outer Diameter of Gas Pipe mm Ф9.52
Ф9.52
Max Distance Height m 10
10
Max Distance Length m 15
20
Note: The connection pipe applies metric diameter.
