Sinclair ASV-35BS - Page 19

- 1
3 -
400mm
400mm
Above or Below
Level
Note: Try you best to put the unit on the horizontal surface for operation. The unit can only operate for a short
Figure 2
Figure 3
Figure 4
Level
Height Varies to Make Unit Level
Level
Level
1077
(588)
400
400x400
OPENING
89
NOTE AIR CONDITIONER DIMENSIONS (ROOF OF UNIT)
720
Unit:mm
