AIR CONDITIONING UNIT
A FEW WORDS ABOUT YOUR NEW
1.
ELECTRICAL
DATA
2.
3.
4.
All wiring must be complied with local and national electrical codes. All wiring
must be installed by qualified electricians. If you have
any questions about the
following instructions, contact a qualified
electrician.
The wiring diagrams are located on the cover of the control box. The assembly unit
wire diagrams are located on the ceiling panel.
5.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
6.
The Electric schematic diagram are subject to change without notice. Please refer
to which one on the unit.
Check the available power supply and resolve any wiring problems BEFORE installing
and operating this unit.
- 1 -
This air conditioner is designed to operate from a 220-240V AC, 50Hz, 1 Phase
power supply.
An all-pole disconnection switch having a contact separation of at least 3mm in all poles should
be connected in fixed wiring.
Including an air switch with suitable capacity, Air switch capacity:10A.
Air switch should be included magnet buckle and heating buckle function, it can protect the
circuit-short and overload.
Thank you for choosing the Recreational Vehicle Air Conditioner.
This manual will supply you with all the information for installation, operation and maintenance.
Take a few minutes to discover how to get the most in cooling comfort and economic operation
from your new air conditioner.
Please keep this manual well for future reference.
