1 Electric Box Assy 100002061319 1 BH
2 Electric Box Sub-Assy 017007060214 1 BF
3 Main Board 300027060176 1 BE
4 Reactor 43130184 1 AS
5 Terminal Board 422000060016 1 AH
6 Wire Clamp 71010103 2 AB
7 Front Grill 22413043 1 AL
8 Front Panel Assy 0153304810 1 AU
9 Axial Flow Fan 10333004 1 AM
10 Chassis Sub-assy 017000060096P 1 AQ
11 Brushless DC Motor 1501308511 1 AX
12 Top Cover Sub-Assy 000051060006 1 AM
13 Motor Support 01703104 1 AL
14 Condenser Assy 011002060205 1 BC
15 Rear Grill 01473009 1 AF
16 Electronic Expansion Valve none 0 -
17 Valve 07100003 1 AK
18 Big Handle 262334332 1 AE
19 Cut off Valve 071302391 1 AM
20 Valve Support 0171314201P 1 AE
21 Right Side Plate Sub-Assy 0130317801 1 AL
22 4-way Valve Assy 030152060087 1 AV
23 Clapboard Sub-Assy 0123338502 1 AK
24 Magnet Coil 4300040050 1 AM
25 Compressor and Fittings 009001060050 1 BK
26 Drainage Connecter 06123401 1 AA
MODEL: ASH-09BIF2 Wall mounted unit: OUTDOOR
The data are subject to change without notice.
