Outdoor
Unit
Model of Outdoor Unit
ASH-09BIF2
Product Code of Outdoor Unit CB419W15801
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXF-A079zE190A
Compressor Oil FW68DA
Compressor Type Rotary
L.R.A. A /
Compressor RLA A 4.6
Compressor Power Input W 790
Overload Protector HPC115/95U1/KSD115
℃
Throttling Method Capillary
Operation temp
o
C 16~30
Ambient temp (cooling)
o
C -15~43
Ambient temp (heating)
o
C -22~24
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter mm Ф7
Rows-n Gap mm 1-1.4
Coil Length (LXDXW) mm 710X19.05X508
Fan Motor Speed rpm 900
Output of Fan Motor W 30
Fan Motor RLA A 0.36
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit m
3
/h 1600
Fan Type Axial-ow
Fan Diameter mm Ф400
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 50/-/-
Sound Power Level (H/M/L) dB (A) 59/-/-
Dimension (WXHXD) mm 782X540X320
Dimension of Carton Box (LXWXH) mm 820X355X580
Dimension of Package (LXWXH) mm 823X358X595
Net Weight kg 27.5
Gross Weight kg 30
Refrigerant R32
Refrigerant Charge kg 0.55
Connection
Pipe
Length m 5
Gas Additional Charge g/m 16
Outer Diameter Liquid Pipe mm Ф6
Outer Diameter Gas Pipe mm Ф9.52
Max Distance Height m 10
Max Distance Length m 15
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
