116
Service Manual
Twist off the screws used for fixing the handle and
v
alve cover
,
pull the handle and v
alve cover
up
ward to remove it.
b
a
a
1. Remove top panel
Remove
handle
valve
top panel
top panel
the 3 screws connecting the top
panel with the front panel and the right side
plate, and then remove the top panel.
2. Remove grille , panel and rear grill
Remove the 2 screws connecting the grille
and the panel, and then remove the grille.
Steps
Procedure
18/24K
