Sinclair MULTI VARIABLE Series Service Manual

45
Service Manual
Step Ps rocedure
7. Remove right side plate
Remove the screws connecting the right side
plate with the chassis and the valve support.
Then remove the right side plate.
8. Remove rear grill
Remove the screws connecting the rear grill
and left side plate, and then remove the rear
grill.
9. Remove left side plate
Remove the screws fixing the left side plate
with the chassis and the condenser support,
and then remove the left side plate.
right side plate
rear grill
left side plate
