panel
screw
wiring cover
Hex nut diameter
1/4'' 15~20
3/8'' 30~40
1/2'' 45~55
5/8'' 60~65
3/4'' 70~75
●
●
Tightening torque (N
.
m)
4.
Add insulating pipe in the indoor drain hose in order
to prevent condensation.
The plastic expansion particles are not provided.
All wires of indoor unit and outdoor unit should be
●
If the length of power connection wire is insufficient,
●
For the air conditioner with plug, the plug should be
●
1.
drain hose
2
.
outlet pipe
2.
tape
NOTE
●
NOTICE
connected by a professional.
Step 7:
Connect wire of indoor unit
please contact the supplier for a new one. Avoid e-
xtending the wire by yourself.
cable-cross
hole
power connection
wire
reachable after finishing installation.
For the air conditioner without plug, an air switch
must be installed in the line. The air switch should
be all-pole parting and the contact parting distance
should be more than 3mm.
Step 6:
Install drain hose
1.
Bind the joint with tape .
indoor unit.
insulating pipe
insulating pipe
drain hose
Wrap the indoor pipe and joint of connection
pipe with insulating pipe, and then wrap it
with tape.
Open the panel, remove the screw on the wiring
cover and then take down the cover.
Connect the drain hose to the outlet pipe of
outlet
pipe
drain hose
Make the power connection wire go through the
cable-cross hole at the back of indoor unit and
then pull it out from the front side.
To Next Page
