User Manual
EM303A General Purpose Inverter
96
ON ON OFF Preset PID Setting 6 Fb-25
ON ON ON Preset PID Setting 7 Fb-26
Xi=41 Preset torque current terminal 1
Xi=42 Preset torque current terminal 2
Xi=43 Preset torque current terminal 3
In preset torque current control mode, 3 function input terminals need to be defined
as the preset torque current terminal. A preset torque current set in F5-15~F5-21 is
selected correspondingly through the state combination of these 3 terminals.
Correlation between preset torque current and the corresponding terminals is as
shown on Table 7-3.
Table 7-3 Correlation between preset torque current and the corresponding terminals
Terminal 3 Terminal 2 Terminal 1 Preset Torque Current
Setting
Corresponding Torque
Current Code
OFF OFF OFF Non-preset Torque Current Defined by F5-11
OFF OFF ON Preset Torque Current 1 F5-15
OFF ON OFF Preset Torque Current 2 F5-16
OFF ON ON Preset Torque Current 3 F5-17
ON OFF OFF Preset Torque Current 4 F5-18
ON OFF ON Preset Torque Current 5 F5-19
ON ON OFF Preset Torque Current 6 F5-20
ON ON ON Preset Torque Current 7 F5-21
Xi=44 Preset current limit terminal 1
Xi=45 Preset current limit terminal 2
Xi=46 Preset current limit terminal 3
When selecting preset current limit, 3 input terminals can be defined as the preset
current limit terminals. A preset current limit set in FA-07
～FA-13 is selected
correspondingly through programming these 3 terminals. See Table 7-4 for
correlation between preset current limit and the corresponding terminals.
Table 7-4 Correlation between preset current limit and the corresponding terminals
Terminal 3 Terminal 2 Terminal 1
Preset Torque Current
Setting
Corresponding Torque
Current Code
OFF OFF OFF Non-preset Current Limit Defined by FC-08
OFF OFF ON Preset Current Limit 1 FA-07
OFF ON OFF Preset Current Limit 2 FA-08
OFF ON ON Preset Current Limit 3 FA-09
ON OFF OFF Preset Current Limit 4 FA-10
ON OFF ON Preset Current Limit 5 FA-11
ON ON OFF Preset Current Limit 6 FA-12
ON ON ON Preset Current Limit 7 FA-13
Xi=47 Start wobbulation operation
