Singer Instruments ROTOR HDA - Target Pinning Options; Target Mixing Options; Pad Pickup Pressure

20
software icon guiDe
ICON NAME DESCRIPTION TAB UNIT MIN MAX DEFAULT
Wet Mix
Source
Source
Mixing
Diameter
Source
Mixing
Speed
Source
Mixing
Cycles
Source
Mixing
Travel
Permanent
offset
Target
Pinning
Pressure
Target
Pinning
Speed
Repeat
Target
Pinning
Target
Pinning
Speed
Target
Pinning
Backoff
Target
Pinning
Overshoot
On/Off
Agar
Agar
Agar
Liquid
Liquid
Liquid mixing can be used to invigorate
the cells in a liquid solution. Liquid
mixing uses either a circular or helical
movement.
The diameter of the mix applied to both
the x and y axis.
The speed at which wet mixes are car-
ried out.
The number of cycles the mix will
include.
The distance that the Pad Head retracts
on 3D mixes.
A permanent offset can be specified
to reset the nominal centre for each
source pinning. This feature is useful
when pinning from source plates that
have been printed to a non-central
location.
The pressure that the Pad Head will use
to push onto the agar.
The speed that the Pad Head will use to
connect to the agar surface.
The number of times each target pin-
ning will repeat.
The speed applied to pinning to wet
source plates.
The retraction distance applied to the
Pad Head after connection to the bot-
tom of the plate.
The amount of travel that will be applied
after connection to the agar surface has
been made.
Boolean
mm
mm/s
Integer
mm
Point
%
mm/s
Integer
mm/s
mm
mm
Off
1
1
1
0.25
-3,-3
0
1
1
1
-0.5
On
3
25
10
15
3,3
100
20
10
19
3
Off
1
25
1
3
0,0
Varies for
each pad
19
1
19
0.5
2
Source>Wet Mix
Source>Wet Mix
Source>Wet Mix
Source>Wet Mix
Source>Wet Mix
Source>Permanent
Offset
Target>Pinning
Target>Pinning
Target>Pinning
Target >Pinning
Target >Pinning
Target>Pinning
SETTING
Speed
dependant
Speed
dependant
