Attaching the presser foot shank
Raise the presser bar
dge/ quilting
dge/ quilting
(a). Attach the (b) as
illustrated. (1)
Lower the presser foot holder (b) until the cut-out (c) is directly
above the pin (d). (2)
Raise the lever (e). Lower the presser foot holder (b) and the
presser foot (f) will engage automatically.
Raise the presser foot. (3)
Raise the lever (e) and the foot disengages.
Attach the e guide (g) in the slot as illustrated.
Adjust according to need for hems, pleats, etc. (4)
Turn power switch to off ("O") when carrying out any of the
above operations!
Attaching the presser foot
Removing the presser foot
Attaching the e guide
Attention:
presser foot shank
