Singer 1507 User Manual

10
Winding the bobbin
- Place thread and spool holder onto spool pin (1).
- For smaller spools of thread place spool holder with
small side next to spool (2).
- Wind thread clockwise around bobbin winder tension
discs (3).
- Thread bobbin as illustrated and place on spindle (4).
- Push bobbin to right (5).
- Hold thread end (6).
- Step on foot control pedal (7).
- Cut thread (8).
- Press bobbin to left (9) and remove.
Please Note:
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the hand wheel will
not turn. To start sewing, push the bobbin winder spindle
to the left (sewing position).
1
2
3
4
5
678
9

Singer 1507 Specifications

General

Type	Semi-automatic sewing machine
Free arm	Yes
Control type	Rotary
Stitch width	5 mm
Product color	White
Buttonhole type	4 Step
Number of programs	-
Sewing machine functions	Sewing
Number of stitch patterns	8
Power supply type	Electromechanical

Weight and Dimensions

Width	425 mm
Weight	7500 g
