Singer 3223 User Manual

Winding the Bobbin
- corresponding .
(1/2)
- Snap thread into thread guide. (3)
- Wind thread clockwise around bobbin winder tension discs.
(4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin spindle to right. (6)
- Hold thread end. (7)
- Step on foot control pedal. (8)
- Cut thread. (9)
- Push bobbin spindle to left (10) and remove.
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the hand wheel will
not turn. To start sewing, push the bobbin winder spindle to
the left (sewing position).
Please Note:
Place thread and spool holder on to spool pin
11
EN
1
2
4
7
8
9
5
6
3
10

Singer 3223 Specifications

General

Stitch Patterns	23
Buttonhole	1-step
Free Arm	Yes
Built-in Needle Threader	Yes
Automatic Bobbin Winding	Yes
Type	Mechanical
Built-in Stitches	23
Stitch Width	5 mm
Max Stitch Length	4 mm
Speed	750 stitches per minute
Bobbin Type	Front-loading
