Singer 3223 User Manual

Inserting the Bobbin
When inserting or removing the bobbin, the needle must
be fully raised.
Attention:
- Remove the extension table, then open the hinged cover.
(1)
- Pull the bobbin case tab (a) and remove the bobbin case. (2)
- Hold the bobbin case with one hand. Insert the bobbin so
that the thread runs in a clockwise direction (arrow). (3)
- Pull the thread through the slit and under the finger. (4)
Leave a 6 inch tail of thread.
- Hold the bobbin case by the hinged latch. (5)
- Insert it into the shuttle. (6)
Turn power switch to off ("O") before inserting or
removing the bobbin.
13
EN
2
6
3
4
5
a
1

Singer 3223 Specifications

General

Stitch Patterns	23
Buttonhole	1-step
Free Arm	Yes
Built-in Needle Threader	Yes
Automatic Bobbin Winding	Yes
Type	Mechanical
Built-in Stitches	23
Stitch Width	5 mm
Max Stitch Length	4 mm
Speed	750 stitches per minute
Bobbin Type	Front-loading
