7
- When inserting or removing the bobbin, the needle must be
fully raised. (1)
- Remove the bobbin cover plate and bobbin. (2)
- Insert the bobbin in the bobbin case with the thread running
in a counterclockwise direction (arrow). (3)
- Pull the thread through the slit (A). (4)
- With a finger held gently on top of the bobbin, place thread
into guides as shown. (5)
- To cut off excess thread pull it toward you to cut it with the
cutter at point (B). Replace the bobbin cover plate. (6)
Attention:
Turn power switch to off (“O”) before inserting or removing
the bobbin.
Inserting the Bobbin
