Singer 3342 User Manual

24
Change the needle regularly, especially if it is showing signs
of wear and causing problems. For best sewing results
always use SINGER
®
Brand Needles.
Insert the needle as illustrated as follows:
A. Loosen the needle clamp screw and tighten again after
inserting the new needle. (1)
B. The at side of the shaft should be towards the back.
C/D. Insert the needle as far up as it will go.
Attention:
Turn power switch to off (“O“) before inserting or removing
the needle.
Needles must be in perfect condition. (2)
Problems can occur with:
A. Bent needles
B. Damaged points
C. Blunt needles
Inserting the needle

Singer 3342 Specifications

General

Stitch Patterns	32
Buttonhole	1-Step
Built-in Needle Threader	Yes
Free Arm	Yes
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Automatic Reverse	Yes
Type	Mechanical
Maximum Stitch Length	4 mm
Maximum Stitch Width	5 mm
Tension Control	Adjustable
Bobbin Type	Front-Loading
Presser Feet	All-purpose, Zipper, Buttonhole, Button Sewing
