Singer 5554 - Winding the Bobbin; Bobbin Winding Procedure; Important Note for Bobbin Winding

Winding the Bobbin
EN
12
- corresponding
. (1/2)
- Snap thread into thread guide. (3)
- Wind thread clockwise around bobbin winder tension discs. (4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin spindle to right. (6)
- Hold thread end securily. (7)
- Step on foot control pedal. (8)
- Trim thread close to the bobbin & then continue winding
until bobbin is full. (9)
- Cut thread, push bobbin spindle to left (10) and remove.
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the .
To start sewing, push the bobbin winder spindle to the left
(sewing position).
Please Note:
Place thread and spool holder on to spool
pin
handwheel turn
1
2
4
7
8
9
5
6
3
10
