Singer 7258Q - Page 32

Page 32/37
Original issue
January 2009
Service Manual
COSMO-7/8
series
Model
17. Electronic component area
AC Power Board
Component number is
87530 for 120V spec. and 87553 for 230V spec.
Be sure to check number printed on board.
5P Connector cord
Connect with CPU
Transformer
Primary
LED lamp
harness
Transformer
Secondary
Main motor DC 120v
YM-45D
87530 & 87553
