Singer 7258Q - Adjustment of Feed Dog Height

Page 8/37
Original issue
January 2009
Service Manual
COSMO-7/8
series
Model
2. Adjustment of feed dog height
Checking:
1. Move feed dog to its highest position by turning hand wheel.
Check to see if feed dog height is as illustrated below.
Adjustment:
1. Remove needle plate. Loosen nut with wrench.
2. Adjust height by turning screw as illustrated. Tighten nut securely after adjustment.
0.9 – 1.1 mm
