24
82387 No. 66
RUFFLER WITH SHIRRING PLATE
Shirring
To attach the shirring plate (see Fig. 20) draw
to the left the slide that covers the bobbin
case, insert the downwardly projecting hooks
on the shirring plate under the edge of the
throat plate, push as far as possible to the
right and press the pin into the hole at the
right of the throat plate, then close the slide
covering the bobbin case.
The lower or separator blade of the ruffler is
fastened by a screw. Loosen the screw, take
off the separator blade and attach the ruffler
to the presser bar as instructed.
FIG. 32
Place the cloth between the ruffling blade and
the shirring plate, lower the ruffler on the
goods and operate as in ruffling.
