Singer QUANTUM STYLIST 9960 - Feed-Dog Height

Singer Quantum Stylist
TM
9960 9
5. Feed-dog height
Check
Check
1. Turn on the machine and set it at straight stitch , lengths; 5.0
2. Bring the feed dog to its highest position by turning hand wheel.
3. The top of the feed dog should now be 0.9 to 1.1 mm above the needle plate.
Adjustment
1. Bring the feed dog to its highest position.
2. Remove the needle plate.
3. Adjust by turning the Allen key screw (A) until a correct feed dog height (0.9-1.1 mm) is obtained.
Turn clockwise: It will be higher
Turn counter clockwise: It will be lower
This Adjustment can be done, without removing the covers, through the hole (B) on the front cover.
4. Re-check the feed dog height.
0.9-1.1 mm
A
