SINGTRONIC KA-2500DSP User Manual

1
CONTENTS
KA-2500DSP Features
1
Specifications
Front Panel Description and Functions
Rear Panel Description and Functions
Advanced Operation
Getting Connected
Troubleshooting
Glossary of Terms
Warranty Information
Cautions and warnings
Safety instructions
1
2
3
4-5
6
7
8
9
10
9
KA-2500DSP FEATURES
Professional Digital Echo with separate repeat and delay controls
3 Mic input with individual volume controls and echo on/of switches
Music master/bass/mid/treble controls
Mic master/bass/treble controls
Mic with lndividual Bass/mid/Trebie controls
source/Level output displays
sub-woofer outpu 1 sets of A/V lnut/output Jacks
Remote control
Digital sound Effect
Excellent Add-on to any karaoke system
SPECIFICATINS
AMPlifier sectin
Power Output(RMS) 1300W+1300W
Input Impedance 47K
Input Sensitivity 150mV
Bass Control +/-15dB(100Hz)
Mid Control +/-15dB(1KHz)
Treble Control +/-15dB(10KHz)
T.H.D <0.1%
Frequency Response 20Hz-20KHz -1dB
Noise Ratio >90dB
Power Source 115V/60Hz
Dimension 430(W)X180(H)X350(D)
Microphone Section
Connector 1/4"TRS/Unbalanced
Input Impedance 1.5K
Input Sensitivity 10mV
T.H.D <0.5%
Frequency Response 20Hz-15KHz -3dB
Noise Ratio >85dB
Bass Control +/-15dB(100Hz)
Mid Control +/-12dB(1KHz)
Treble Control +/-15dB(10KHz)
Digital Echo Up to 300ms
Ω
Ω
FEATURES
