Sinoboom TB18 Plus - Page 84

© Apr 2022 5-32 TB18 Plus&20J Plus Maintenance Manual
MAINTENANCE PROCEDURES
Figure 5-37 Deutz D2.9L4 engine oil drain
valve
Figure 5-38 Deutz TD2011L04i engine oil
drain valve
Figure 5-39 Cummins QFS2.8t3NA60
engine oil drain valve
Figure 5-40 WEICHAI WP3.2 engine oil
drain valve
BURN HAZARD
Do not come in contact with the hot
engine oil when draining to avoid
burns.
NOTICE
The waste engine oil should be collected in a
suitable vessel for disposal or recycling. The
waste engine oil should be treated in compliance
with the environment laws or regulations.
7. Close the drain valve.
8. Add new engine oil. For the recommended viscosity
grade of the engine oil, please reference A-8
Inspect Engine Oil Level, page 5-8.
C-4 Replace Engine Oil Filter
NOTICE
Replace the engine oil filter each time the engine oil
is replaced.
1. Open the right turntable cover and locate the
engine oil filter. Remove the filter.
