© Jun 2022 6-4 TB24 Plus&26J Plus Operation Manual
PRE-OPERATION FUNCTION TEST
Figure 6-3 Ground Controller Display
Table 6-3
1. Current work hours
13. Low diesel/battery alarm 25. Engine high idle
2. Platform load
14. Engine oil pressure alarm 26. Engine low idle
3. Diesel/Battery gauge
15. Generator mode indicator-FE
mode
27. Operating position
4. Accumulated work hours
16. Water temp alarm 28. Non-operating position
5. Tachometer
17. Hydraulic generator/inverter on
29. Boom horizontal reach
6. Setup menu
18. FE mode indicator
30. Boom angle above horizontal
7. Machine info 19. Chassis tilt alarm
31. Boom length
8. Turntable info 20. Platform tilt alarm
32. Platform height
9. Platform info
21. Heavy load indicator
33. Overload limit
10. Alarm message
22. Overload alarm
34. Drive limit (operating position)
11. Fault alarm
23. Axle extended in place
35. Drive and boom functions
allowed
33
E
20
40
60
80
F
60 %
2.40 m
9.92 m
2.44 °
10.92 m
0
1
2
3
4
5
0
RPM
X1000
H H
11.5
0011.5
32
15
1 2
6
5
7
4
10
1112
9
13
8
14
3
20 1925 24 1622 172123 182627
30
28
29
31
KG
33
DR
D/B
34
35
FE
