SIP 01480 - Page 26

25
NO. DESCRIPTION QTY NO.
DESCRIPTION
QTY
1 Underprop 4 2
Supporting plate
2
3 Hex nut M6 12 4
Washer Ø6
12
5 Linking plate I 1 6
Linking plate II
1
7 Hex bolt M6X20 12 8
Hex nut M5
4
9 Washer Ø5 4 10
Phillips screw M5X15
4
11 Three-way pipe 1 12
Screw M6X16
4
13 Washer Ø6 4 14
Saw faceplate
1
15 Big washer Ø6 4 16
Hex nut M6
4
17 Screw M5X14 2 18
Threaded shaft support
1
19 Washer Ø5 2 20
Hex locking nut M5
2
21 Threaded nut 1 22
Limitative bush
2
23 Set screw M8X6 2 24
Threaded shaft
1
25 Set screw M5X8 2 26
Bearing rack
1
27 Washer Ø5 3 28
Hex bolt M5X12
3
29 Bearing 6000 1 30
“C” ring Ø26
1
31 C ring Ø10 1 32
Hand wheel
1
33 Set screw M6X12 1 34
Screw M6X45
4
35 Sliding table assembly 1 36
Hex nut M8
2
37 Washer Ø8 2 38
Screw M8X10
2
39 Guide rail 1 40
Screw M6X16
2
41 Washer Ø6 2 42
Screw M6X10
4
43 Washer Ø6 4 44
Protective cover
1
45 Hex nut M6 4 46
Washer Ø6
4
47 Hex bolt M6X20 4 48
Switch box
1
49 Box assembly 1 50
Protective cover
1
51 Washer Ø6 4 52
Screw M6X10
4
53 Outstretched arm 2 54
Angle iron
4
55 Big washer Ø6 8 56
Hex nut M6
8
57 Hex nut M6 8 58
Washer Ø6
8
59 Hex bolt M6X16 8 60
Miter gauge
1
61 Locking handle 1 62
Pin 3X12
1
63 Locking shaft 1 64
Big washer Ø8
2
65 Space bush 2 66
Saw assembly
1
67 Big washer Ø8 1 68
Hex locking nut M8
1
69 Hex nut M8 1 70
Hex nut M6
4
71 Washer Ø6 4 72
Supporting rear
2
73 Screw M6X30 4 74
Hex nut M6
8
75 Big washer Ø6 8 76
Extending table
2
77 Hex bolt M6X16 8 78
Screw M4X6
1
79 Tooth washer 4 1 80
Pointer
1
81 Screw M6X16 8 82
Washer Ø6
8
83 Hex nut M6 8 84
Washer Ø6
8
85 Supporting plate 4 86
Hex locking nut M6
4
87 Washer Ø6 4 88
Main table
1
89 Screw M6X45 4 90
Vertical fence
2
91 Fence assembly 1 92
Hex bolt M6X16
8
93 Insert 1 94
Screw M6X10
2
95 Screw M4X10 3 96
Aluminous plate
1
97 Throat banding Ø70 2 98
Dust tube Ø70
1
99 Throat banding Ø32 2 100
Dust tube Ø32
1
101 Plug 1 102
Tightener M16
1
103 Screw ST3.8X10 2 104
Switch
1
105 Screw ST3.8X16 4 106
Switch cover
1
107 Hex nut M5 4 108
Switch fixing plate
2
109 Screw M5X12 4 110
Tightener M16
2
111 Hex bolt M6X12 1 112
Washer 6
1
113 Connecting bolt 1 114
Hex nut M6
1
115 Pick rod 1
11. PARTS LIST
