Diagram D-Rip fence
Diagram
E-Mitre ga
uge
NO. DESCRIPTION QTY NO. DESCRIPTION QTY
1 T-shaped plate 1 4 Washer Ø8 1
3 Miter gauge 1 5 Long handle 1
NO. DESCRIPTION QTY NO. DESCRIPTION QTY
1 Locking handle 1 2 Hex bolt M6X25 1
3 Washer φ6 1 4 Fixing plate 1
5 Locking bracket 1 6 Long fence 1
11 Socket cap screw M6X30 2 12 Rubber tray 1
13 Hex nut M6 1 14 Large erφ6 1
14. EXPLODED DRAWING & PARTS LIST
