SIP 01594 User Manual

10
TECHNICAL SPECIFICATION
Note: If any of the above are missing or damaged, contact your distribu-
tor immediately.
CONTENTS & ACCESSORIES
Name 12” Metal Cutting Bandsaw 1PH 12” Metal Cutting Bandsaw 3PH
Part number 01594 01595
Input Voltage 230v 400v
Circular 45˚ 127mm 127mm
Circular 90˚ 178mm 178mm
Rectangle 45˚ 120 x 125mm 120 x 125mm
Rectangle 90˚ 178 x 305mm 178 x 305mm
Blade speed 22, 33, 45 & 65 mtr/min 22, 33, 45 & 65 mtr/min
Blade size 2362 x 0.9 x 19mm 2362 x 0.9 x 19mm
Motor power 1.5HP (1.1kw) 1HP (750w)
Drive V-belt V-belt
Packed dimensions 1250 x 450 x 1150mm 1250 x 450 x 1150mm
Net weight 170 kg 170 kg
Gross weight 192 kg 192 kg
A Manual
B Wheel Set
C
Cut off stop
D
Cut off stop thumb
screw
E Split pin
F Cut off stop shaft
G Axle
A
B
C
D
E
F
G
27
EXPLODED DIAGRAM
SAW BASE
