PowerConnect Vehicle Dock
Color-Coded Connections
The color-coded PowerConnect Vehicle Dock makes it simple to connect. Just match the colors on
the cable ends to the colors on the dock to see what goes where.
Rear View
ANT (Silver)
Connection for the
Magnetic Mount
Antenna.
AUDIO (Green)
Connection for
Aux In Cable
PWR (Red)
Connection for the
PowerConnect Power
Adapter.
FM (Blue)
Connection for optional
FM Direct Adapter
(sold separately).
AUDIOANT PWRFM
Wire Guide
The PowerConnect Vehicle Dock has a wire guide at the top rear that can help you to organize the
cables and wires connected to the dock. If you need to bring a cable or wire from one side of the
dock to the other, utilize the wire guide by looping the cable though the wire guide as shown.
re Guide
