P32
Introduction
H
L
針與線之冷卻與潤滑
LUBRICATE AND THE COOLING
OF NEEDLES AND THREADS
圖 30/Fig.30
圖 29/Fig.29
3. 每天必須檢視，如果油已低於油標指示窗
之下限，必須加注新油，當機器開始運轉，
操作前，必須檢視整個潤滑系統是否順
暢。
* 開箱之新機器或許久未使用而重新要使用
時，請在針棒上下部分加油潤滑。
3.Be sure to check every day and refill
the oil,if oil level is lower than line L of
oil level gauge.
*Before starting a brand new machine or
a machine which has not been used of
more than a couple of week,oiling the
needle bar.
將矽油注入①及
②油槽以防止斷線 ( 圖 30)
Fill reservolr ① and
②
with silicon oil to
prevent the thread from breaking.(Fig.30)
1
L
I
S
C
A
L
O
N
I
2
I
N
O
L
A
C
L
S
I
