G 3
輸入裝置
Input
Device
1.控速器( +12V ) Foot Switch :
( +12V / Start / VC / Knee SW / 0V / Trimmer ) Speed Controller
2.Safety Switch : ( +12V / Safety SW / PSD / 0V )
3.選針盒 Operation Box : ( U Sw. / R1 in / +12V / T1 out / 0V / CKU )
4.Encoder : ( +5V / Up / Down / A Phase / B Phase / R / S / T / 0V )
5.抬壓腳 Foot Lifter : ( OF / +24V )
6.倒縫開關(操作按鍵開關,手動控制倒縫電磁閥)
Backstitch Switch (Operation Key Switch, Manual Control Backstitch Solenoid Value)
7.掃線電磁閥電源開關 ，直接串接電磁閥電源線，控制掃線電磁閥 ON/OFF
Sweep Line Solenoid Value Power Switch, Direct Tandem Solenoid Valve Power
Cord, Control Sweep Line Solenoid Valve ON/OFF
輸出輸入裝置規格與功能
The Specification and Function of Input and Output Device
項目 Item
內 容 說 明 Illustration
輸出裝置
Output
Device
1.
提供
+12V / 0.5A ,
控制
LED Lamp
Supply +12 V/ 0.5A, Control LED Lamp
2.故障現象顯示 LED
Trouble Signal Display LED
3.車頭功能 Sewing Machine : 14 Pin Connecter
Pin1 : OA , Pin 8 : +24V
 切線電磁閥(LU25-E)(行程 6mm,阻抗 7.5ohm,吸力 5.5Kg/mm)
Trimmer Solenoid (LU25-E)(distance 6mm mpedance .5ohm,suction5.5Kg/mm)
Pin2 : OB , Pin 9 : +24V
 掃線電磁閥(GLU36)(行程 7mm,阻抗 8.5ohm,吸力 2.5Kg/mm)
Thread Wiper Solenoid (GLU36)
(distance7mm,impedance8.5ohm,suction2.5Kg/mm)
Pin6 : OC , Pin13 : +24V
 倒縫電磁閥(LC209-A)(行程 8mm,阻抗 5.6ohm,拉力 4Kg/mm)
Backstitch Solenoid (LC209-A)(distance 8mm,impedance 5.6ohm, Pull 4Kg/mm)
Pin5 : INE 倒縫開關 , Pin12 : 0V
 操作按鍵開關,手動控制倒縫電磁閥
Pin5 : INE Backstitch Switch , Pin12 : 0V
 Operation Key Switch, manual control backstitch solenoid valve
Pin10 : Earth 接地 , Pin3 & 4 & 11 : NC
設定裝置
Setting
Device
1.
內部具有
DIP SW
裝置，
The DIP SW Device is installed in the internal machine.
(1).起始倒縫 Start Backstitching
(2).終止倒縫 Stop Backstitching
(3).上停針 / 下停針 Upper Stop Pin / Down Stop Pin
(4).慢速起縫 Stitching with slow speed
2.外部具有旋轉 VR 可調整 Max rpm ~ 0 rpm 之間的最大可運轉速
The rotation VR in the external machine can adjust the maximum speed within Max
rpm ~ 0 rpm.
