ENGINE
Type
No
of cylinders
Bore
Stroke
Displacement
Compression ratio (corrected)
Maximum horsepower
R.P.M. *
Carburetor type
Carburetor adjustment:
air screw
idle speed
Cooling system capacity:
-
Sl
Imp.
u.s.
Antifreeze/water mixture (% by volume}
Thermostat
Radiator pressure cap
Torque:
- engine head nuts
- crankcase nuts
- magneto ring
nut
- crankcase/engine support screws
- exhaust manifold
bolts
CHASSIS
Length overall
Width overall
Height overall
Ski
stance (center
to center)
Torque:
steering arm/ski leg bolt
- steering column/handlebar
Weight
Bearing area
Ground pressure
BRAKE
Type
Lining minimum thickness
Control lever adjustment
N.A.: Not applicable
FORMULA PLUS
536
2
72.0 mm (2.835 in)
64.0 mm (2.520 in)
521.2 cm3 (31.81 in3)
6.12:1
7250 R.P.M.
FORMULA PLUS LT
536
2
72.0 mm (2.835 in)
64.0 mm (2.520 in)
521.2
cm
3
(31.81 in3)
6.12:1
7250 R.P.M.
Variable Venturi, float type
1 1/3 turns
1800-2000 R.P.M.
4.2 L
148 oz
142 oz
60/40
42°C
90 kPa
(107°F)
(13 lb/in
2
)
M8: 20 N•m (15 lbf•ft)
M6: 9 N•m (80 lbf•in)
M8: 20 N•m (15 lbf•ftl
M22: 100 N•m (74 lbf•ft)
M8: 25 N•m (18 lbf•ft)
M8: 21 N•m (15 lbf•ftl
271.8 em
(107 in)
104.1 em
(41 in)
99 em
(39 in)
92.1 em
(36.25 in)
25 N•m
(18 lbf•ft)
26 N•m
(19 lbf•ft)
226.8 kg
(500 lb)
6348 cm
2
(984 in2)
3.57
kPa
(.508 lb/in
2
)
1 1/3 turns
1800-2000 R.P.M.
4.2 L
148 oz
142 oz
60/40
42°C
90 kPa
{107°F)
(13 lb/in
2
)
M8: 20 N•m (15 lbf•ftl
M6: 9 N•m (80 lbf•in)
M8: 20 N•m (15 lbf•ft)
M22: 100 N•m {74 lbf•ft)
M8: 25 N•m (18 lbf•ft)
M8: 21 N•m (15 lbf•ft)
271.8 em
(107 in)
104.1 em
(41 in)
99 em
(39 in)
92.1 em (36.25 in)
25 N•m
(18 lbf•ft)
26 N•m
{19 lbf•ft)
240 kg
(5291b)
7226 cm
2
(1182 in2)
3.15 kPa
{.448 lb/in2)
Disc, self-adjusting
Fixed pad
must project 1 mm (1/32 in}
minimum from caliper.
13 mm
(1/2 in) minimum distance from handlebar
grip when
fully applied.
*The maximum horse R.P.M. is applicable with engine on the vehicle. It may be different under certain circum-
stances and Bombardier Inc. reserves the right to modify it without any obligation.
