SPECIFICATIONS
SYSTEM MODELS
ELECTRICAL SYSTEM (CONT'D) 600 HO E-TEC
F 1: Battery 30 A
F2: Relay2coil,
start button, gauge
5A
F 3: Horn (optional) 10 A
F4: Relay2power
(cooling fan)
15 A
R 1: Fuse 1, fuse 2, fuse 4
Fuses/
Relays/
Capacitor
R2:
Cooling fan relay
ELECTRICAL SYSTEM 600 ACE
Lightning system output 12V/650 W
Headlights bulb HI/LOW beam
2 x 60/55 Watts (H-4)
Taillight bulb 2 x P 21/5 W
Type
NGK CR7EB
Spark plug
Gap
.8 mm (.031 in)
F 1: Fuse 2, fuse 4,
relay 1, relay 2, relay 3,
voltage regulator
30 A
F 2: Relay coils, start
button, gauge
5A
F 3: Fuel pump,
starter solenoid
10 A
F4: Relay4 10A
F 5: Fuel injectors,
ignition coils
10 A
F 6: Gauge, ECM,
camshaft position sensor
10 A
F 7: 12-volt power
outlet, heated grips,
heated throttle lever
10 A
F 8: Lights 20 A
F 9: Horn (optional) 5 A
Fuses
F 10: Rear 12-volt power
outlet (optional)
5A
98
