90
Installation
All Models
The maximum drive belt life span is obtained when the belt has the
proper rotation direction. Install it so the arrow printed on belt is point-
ing at front of vehicle.
CAUTION: Do not force or use tools to pry the belt into place, as this
could cut or break the cords in the belt.
Clean sheaves of both pulleys using BOMBARDIER Parts Cleaner
(P/N 413 711 809).
To install the drive belt, first place belt between drive pulley sheaves.
Then, between driven pulley sheaves, finishing with bottom.
Reposition and lock driven pulley support, on Tundra R.
Remove belt installer. Reinstall belt guard.
Drive Chain Tension
Skandic LT
NOTE: Tundra R is equipped with an automatic tensioner. Skandic WT/
SWT/WT LC are equipped with gearbox without chain.
Remove hair pin.
Fully tighten tensioner adjustment screw by hand, then back off only
far enough for hair pin to engage in locking hole.
Mmo2002-001a.book Page 90 Friday, January 12, 2001 1:56 PM
