Skil 1817 - Functional Description and Specifications

-7-
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Fix Base Router
FIG. 1
FIG. 2
HANDLE
FINE
ADJUSTMENT
KNOB
CHIP DEFLECTOR
BIT ROTATION ARROW
2-POSITION
SLIDE "ON/OFF"
SWITCH
VENTILATION
OPENINGS
BASE CLAMP
LEVER
SUB-BASE
BASE (TYPE A)
BASE RELEASE
BUTTON
BASE CLAMP
TENSION
ADJUSTMENT
SCREW
COLLET LOCK
INDICATOR RING
HANDLE
