Skil 4570 - Functional Description and Specifications; Cordless Jigsaw Overview

&;;8
Model number 4570
Voltage rating 18 V
No load speed n
0
0-2100/min
-D59A9-<-/5@51?
Stroke length 5/8"
Blade Thickness Minimum 0.8mm -
Maximum 1.5mm
Wood 2"
Aluminum 3/8"
Mild steel 3/16"
4->31>!5-0 SC118 or SC118B
-@@1>E<-/7 SB18A & SB18B
4->31>55;: SC118B-LI
-@@1>E<-/7 SB18B-LI
Voltage rating 120 V 60 Hz
-8-
A:/@5;:-81?/>5<@5;:-:0%<1/525/-@5;:?
5?/;::1/@.-@@1>E<-/72>;9@;;8;><8-/1@41?C5@/45:@418;/710;>
;22 <;?5@5;: .12;>1 9-75:3 -:E -??19.8E -06A?@91:@? ;> /4-:35:3
-//1??;>51? Such preventive safety measures reduce the risk of starting the tool
accidentally.
!
WARNING
;>081??53?-C
VENTILATION
OPENINGS
GEAR
HOUSING
TOOL-LESS BLADE
CHANGE COVER
ORBIT
CONTROL
LEVER
FOOT
TRIGGER
SWITCH
GUIDE
ROLLER
BATTERY
PACK
SAFETY SWITCH
FIG. 1
PLUNGER
BATTERY
RELEASE BUTTON
BUILT IN
WORK LIGHT
BATTERY RELEASE
BUTTON
* BUTTON
* BATTERY CHARGE
CONDITION INDICATOR
LIGHTS
* NOT AVAILABLE ON ALL MODELS
