INTRODUCTION
● This tool is intended for grinding, cutting and deburring
metal and stone materials without the use of water; with
the appropriate accessories the tool can also be used for
brushing and sanding
TECHNICAL SPECIFICATIONS 1
SAFETY
GENERAL
● Read and save this instruction manual (pay special
attention to the safety instructions at the back) 2
● Only use this tool for dry grinding/cutting
● Only use the flanges which are supplied with this tool
● This tool should not be used by people under the age of
16 years
● Always disconnect plug from power source before
making any adjustment or changing any accessory
ACCESSORIES
● Use the original SKIL accessories which can be obtained
from your SKIL dealer
● For mounting/using non-SKIL accessories observe the
instructions of the manufacturer concerned
● Use only accessories with an allowable speed matching
at least the highest no-load speed of the tool
● Do not use damaged, deformed or vibrating
grinding/cutting discs
● Handle and store grinding/cutting discs carefully to avoid
chipping and cracking
● Protect accessories from impact, shock and grease
● Do not use a grinding/cutting disc that is larger than the
maximum recommended size
● Only use grinding/cutting discs with a hole diameter which
fits mounting flange D 6 without play; never use reducors
or adaptors to fit large-hole grinding/cutting discs
● Never use grinding/cutting discs with a threaded hole, of
which the thread is not long enough to accept the spindle
length of the tool
● Never use accessories with a "blind" threaded hole
smaller than M14 x 21 mm
OUTDOOR USE
● Connect the tool via a fault current (FI) circuit breaker
with a triggering current of 30 mA maximum
● Only use an extension cord which is intended for outdour
use and equipped with a splashproof coupling-socket
BEFORE USE
● Before using the tool for the first time, it is recommended
to receive practical information
● Do not work with materials containing asbestos
● Be careful of hidden electrical wires or gas- and water
pipes; check the work area, for instance with a metal
detector
● Be careful when cutting groves, especially in supporting
walls (slots in supporting walls are subject to country-
specific regulations; these regulations are to be observed
under all circumstances, so before beginning work,
consult with the responsible structural engineer, architect
or construction supervisor)
● Clamp the workpiece in case it does not remain
stationary from its own weight
● Do not clamp the tool in a vice
● Use completely unrolled and safe extension cords with a
capacity of 16 Amps (UK 13 Amps)
● Wear protective glasses and gloves, hearing protection 3,
a dust mask, and sturdy shoes; when necessary, also wear
an apron
● Always mount auxiliary handle A 6 and protective guard
B 6; never use the tool without them
● Be sure tool is switched off when plugging in
DURING USE
● Always keep the cord away from moving parts of the
tool; direct the cord to the rear, away from the tool
● If the cord is damaged or cut through while working, do
not touch the cord, but immediately disconnect the plug;
never use the tool with a damaged cord
● Push spindle-lock button G 6 only when spindle C 6 is
at a standstill
● Keep hands away from rotating accessories
● When grinding metal, sparks are generated; keep other
persons and combustible material from work area
● In case of electrical or mechanical malfunction,
immediately switch off the tool and disconnect the plug
● In case the cutting disc is blocked, resulting in jerking
forces on the tool, immediately switch off the tool
● In case of current interruption or when the plug is
accidentally pulled out, unlock the on/off switch
immediately and put it in the OFF-position in order to
prevent uncontrolled restarting
● Do not apply so much pressure on the tool that it comes
to a standstill
AFTER USE
● Before you put down the tool, switch off the motor and
ensure that all moving parts have come to a complete
standstill
● After switching off the tool, never stop the rotation of the
accessory by a lateral force applied against it
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
● Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug
● If for any reason the old plug is cut off the cord of this tool,
it must be disposed of safely and not left unattended
USE
● Mount auxiliary handle A 4
● Mount protective guard B 5
! ensure that the closed side of the protective guard
always points to the operator
● Mounting of accessories 6
! disconnect the plug
- clean spindle C and all parts to be mounted
- tighten clamping flange E with spanner F while
pushing spindle-lock button G
- for removing accessories handle vice-versa
! grinding/cutting discs become very hot during use;
do not touch them until they have cooled down
! always mount backing pad when using sanding
accessories
4
