Functional Description and Specifications
GRINDING
WHEEL
GUARD
RELEASE / LOCK
LATCH
WHEEL
GUARD
VENTILATION
OPENINGS
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
NOTE: For tool specifications refer to the nameplate on your tool.
Model number 9320 9325
Max. wheel diameter 4 1/2" (115mm) 4 1/2" (115mm)
Spindle thread 5/8"-11 UNC 5/8"-11 UNC
Max. wire wheel 4" Dia. 4" Dia.
Max. wire cup brush 3" Dia. 3" Dia.
Max. sanding disc 4 1/2" Dia. 4 1/2" Dia.
Max. cut off wheel 4 1/2" Dia. 4 1/2" Dia.
Max. dry diamond wheel 4 1/2" Dia. 4 1/2" Dia.
Angle Grinders
SPINDLE LOCK
SIDE
HANDLE
SWITCH
BUTTON
