SYMBOLS (CONTINUED)
IMPORTANT:
Some of the following symbols may be used on your tool. Please study them
and learn their meaning. Proper interpretation of these symbols will allow you to operate the
tool better and more safely.
Symbol Name Designation/Explanation
V Volts Voltage (potential)
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
kg Kilograms Weight
lb Pound Weight
ml Milliliter Volume
.oz Fluid Ounce Volume
min Minutes Time
s Seconds Time
Wh Watt-hours Battery capacity
Ah Ampere-Hours Battery capacity
Ø Diameter Size of drill bits, grinding wheels, etc.
n
0
No load speed Rotational speed, at no load
n Rated speed Maximum attainable speed
…/min
Revolutions or reciprocation
per minute
Revolutions, strokes, surface speed,
orbits, etc. per minute
SPM Strokes Per Minute Stroke speed, at no load
0 Off position Zero speed, zero torque...
°C Celsius temperature Temperature
°F Fahrenheit temperature Temperature
IPX4 Ingress Protection Degree Protection from splashing water
Arrow Action in the direction of arrow
Direct current Type or a characteristic of current
Li-ion RBRC seal
Designates Li-ion battery recycling
program
Read manual symbol Alerts user to read manual
