14
SPECIFICATIONS
Rated voltage 40V d.c.
Guide Bar Length 14’’ (350mm)
Chain Pitch 3/8” (9.5mm)
Chain Gauge 0.043” (1.1mm)
Chain Type CL14352PB (TriLink)
Guide Bar Type M1431452-1041 (TriLink)
Oil Tank Capacity 5.0 . oz (150ml)
Recommended Working Temperature 5~104°F (-15~40°C)
Recommended Storage Temperature 32~104°F (0~40°C)
RECOMMENDED BAR AND CHAIN FOR THIS CHAIN SAW
Part Name Type Model Number
Guide Bar M1431452-1041 (TriLink) SBR1400
Saw Chain CL14352PB (TriLink) SCN1400
Guide Bar and Saw Chain Kit SBC1400
Chain Kickback Brake Handle
Serves as the lever for chain brake activation. It also provides protection against projecting
branches and helps prevent the left hand from touching the saw chain if it slips off the front
handle.
Trigger Switch
Turns the chain saw On and Off.
Lock-off Button
Helps to prevent accidental or unauthorized activating of the trigger switch. It must be
depressed before the trigger switch can be activated.
Oil Tank Cap
Seals the oil tank.
Oil-Inspection Window
Provides a view of the oil level in the oil tank.
Guide Bar
Supports and guides the saw chain.
Chain Sheath
The chain sheath keeps the operator from coming in contact with the sharp chain blades when
the tool is not in use. It also helps keep the chain blades from being nicked or damaged when
the tool is in transportation and storage.
