Parts List
•
If ANY of the parts are
missing, DO NOT attempt
to assemble, install, or use your router table
until the missing parts have been found or
replaced and your router table has been
properly and correctly assembled per this
manual.
•
For missing parts or technical assistance,
call 1-877-SKIL999 (877-754-5999).
•
In order to simplify handling and to minimize
any damage that may occur during shipping,
your router table comes mostly assembled.
Repositioning of some parts will be required.
•
Separate all parts from the packaging
materials and check each part against the
illustrations and the parts lists to make sure
that all parts have been included. Do this
before discarding any of the packaging
material.
Key No. Description Quantity
A ROUTER TABLE ASSEMBLY COMPONENTS
(shipped preassembled)
1 Router Tabletop 1
2 Insert Plate 1
3 Steel Miter Channel (includes 3 #10-32 x 7/8" screws, item 28) 1
4 Router Mounting Bracket (not shown) 4
5 Small Star Clamping Knob (not shown) 4
6 Front Table Housing 1
7 Rear Table Housing 1
8 Left Folding Steel Leg Assembly 1
9 Storage Bag 1
10 Right Folding Steel Leg Assembly 1
11 Insert Ring Set 1
11A Insert Ring w/ 1/2" dia. hole 1
11B Insert Ring w/ 3/4" dia. hole 1
11C Insert Ring w/ 1" dia. hole 1
11D Insert Ring w/ 1¼" dia. hole 1
11E Insert Ring w/ 1½" dia. hole 1
B SWITCH BOX ASSEMBLY COMPONENTS
12 Switch Box Assembly (with lockout key) 1
13 Lockout Key (replacement part) 1
C FENCE ASSEMBLY COMPONENTS
(shipped preassembled)
14 Router Table Fence 1
15
Overhead Guard Assembly (includes spacer)
1
16 Faceplate 2
17 Outfeed Shim Plate (may be attached to outfeed side of fence) 1
18 Clamping Knob 7
19 Featherboard 1
D MITER GAUGE ASSEMBLY COMPONENTS
20 Miter Bar 1
21 Protractor Head 1
22 Small Clamping Knob 1
ITEMS NOT ILLUSTRATED
23 Operating/Safety Instructions 1
Refer to Parts List below and on pages 8–9.
