Note
♦ Further information and how to use the set ⇒ Owner's Man‐
ual of the car tool kit.
♦ Refer to the table in the ⇒ Owner's Manual of the release
tool set in order to allocate the correct release tools.
2.3 Tool descriptions
⇒ p2.3.1 lier with insert”, page 43
⇒ t2.3.2 ools for contacts”, page 44
⇒ t2.3.3 ools for single cable seals”, page 44
⇒ s2.3.4 tripperVAS 1978/3”, page 45
⇒ b2.3.5 lower, 220 V, 50 HzVAS 1978/14”, page 46
⇒ p2.3.6 liersVAS 1978/1A”, page 46
2.3.1 Stop plier with insert
The stop plier without insert -VAS 1978/1- with the insert for
stop plier -VAS 1978/2- is part of the wiring loom repair set
-VAS 1978B-. In addition, the interchangeable head 0.13 - 05
mm
2
-VAS 1978/1-3- is available.
Crimp
connec‐
tor col‐
our
Crimp‐
ing re‐
cess
colour
Cable cross-section Inter‐
changeable
head
trans‐
parent
none
0.13 mm
2
/0.35 mm
2
/0.5
mm
2
-VAS
1978/1-3-
yellow yellow
0.35 mm
2
-VAS
1978/1-1-
red red
0.5 mm
2
- 1.0 mm
2
-VAS
1978/1-1-
blue blue
1.5 mm
2
- 2.5 mm
2
-VAS
1978/1-1-
yellow yellow
4.0 mm
2
- 6.0 mm
2
-VAS
1978/2A-
Citigo 2012 ➤, Citigo-e iV 2020 ➤, Enyaq 2021 ➤, Enyaq Coupe 2021 ➤, Fabia 2000 ...
Electrical System - general notes - Edition 12.2021
2. Wiring harness repair 43
