Do-it-yourself
Emergency equipment and self-help
Emergency equipment
Placement of the first aid kit and warning triangle
Fig. 310 Placing of the first-aid kit and the warning triangle: Variant
1/detach warning triangle
Fig. 311
Placing of the first-aid kit and
the warning triangle: Variant 2
The following information applies for the first aid kit and warning triangle from
the ŠKODA Original Accessories.
Placing the first-aid kit
The first-aid kit can be attached by a strap to the right-hand side of the boot
» fig. 310 or » fig. 311.
Depending on the equipment fitted, in the same place a storage compartment
may be located in which the first aid kit can be stowed.
Placing of the warning triangle - variant 1
The warning triangle can be inserted into the recess under the loading edge
and secured with the fastener tape» fig. 310 .
›
To release, press the clasp on the tape in the direction of arrow
1
fold open
the belt
A
in the direction of arrow
2
» fig. 310.
›
To secure, fold up the belt
A
against the arrow direction
2
until it locks in-
to place.
Placing of the warning triangle - variant 2
The warning triangle can be stored in the recess under the loading edge
» fig. 311. Before it is taken out, the floor covering of the luggage compartment
must be raised.
WARNING
Always secure the first aid kit and warning triangle properly - otherwise
there is a risk of injury to the occupants in the event of sudden braking or a
vehicle collision.
Placement of reflective vest
Fig. 312
Stowage compartment for the
reflective vest in the front door
The reflective vest can be stowed in the stowage compartment
A
inside the
storage compartment of the front door » fig. 312.
It is possible to store the reflective vests for the passengers on the rear seat in
the storage compartment in the rear doors.
269
Emergency equipment and self-help
