SKOPE Surface and Recessed Wall Fan Heater
Installation and Operating Instructions
Surface Mounted Models: 989E, 990E
Installation Diagram
989E = 372mm
990E = 437mm
380
144
220
Cable entry position
Fixing screws (4)
Floor level
Heater body outline
Front panel screws (2)
Fixing holes (4)
10
28
Adjacent wall
Heater body
200 min.
300
min.
Front panel hinged down
