SKOPE Surface and Recessed Wall Fan Heater
Installation and Operating Instructions
Control Panel
Control Functions
* Ensure the heater can operate safely, if operated on the Freeze Guard setting.
1
POWER BUTTON
Press to START or STOP the heater.
2
FAN ONLY INDICATOR
To set the heater to Fan Only setting, press the
button until the Blue/Green Fan Only indicator is lit.
3
FREEZE GUARD INDICATOR *
When the heater is set to the Freeze Guard setting, it will
switch on if the temperature detected by the electronic
controller falls below 5°C. To set the heater to Freeze
Guard setting, press the selector buttons until the Orange
Freeze Guard indicator is lit.
4
SELECTOR BUTTON
Press to DECREASE the temperature setting.
5
SELECTOR BUTTON
Press to INCREASE the temperature setting.
6
TAMPER LOCK BUTTON
Activating the Tamper Lock button will ensure that the
temperature setting can not be changed, yet the heater is
still able to be turned on or off.
To activate the Tamper Lock, hold down the button for
approx. 3 seconds, until you hear a beep and the Red
Tamper Lock indicator is lit.
To deactivate this function, repeat the operation.
4
1
56
Freeze Guard Indicator (Orange)
23
Temperature Indicators (Red)
Fan Only Indicator (Blue/Green)
Tamper Lock Indicator (Red)
